The HT-3DF enclosed laser engraving station is engineered for high-performance metal marking, delivering accurate and detailed results. Its robust enclosure effectively contains fumes, minimizes glare, and provides operator protection, all while upholding superior engraving precision. This system is particularly well-suited for industrial environments, guaranteeing clean and consistent marking on a variety of metals, including steel, aluminum, stainless steel, copper, and titanium. Constructed with durability and precision in mind, the HT-3DF is an ideal solution for applications such as high-end jewelry manufacturing and mold engraving.
| Model | HT-3DF20/30/50/100 |
| Laser power | 20/30/50/100W |
| Engraving area | 100×100-300×300((mm)Optional) |
| Light wavelength | 1064nm |
| Engraving speed | ≤7000mm/s |
| Repeating frequency | 1-600KHz |
| Beam Quality | M2<1.6 |
| Minimum line width | 0.01mm |
| Carving depth | ≤5mm |
| Repeating precision | ±0.002mm |
| Cooling Mode | air cooling |
| Integrity power | <2KW |
| power supply | 220V/50Hz/32A |
