The Handheld Laser Marking Machine offers a revolutionary approach to industrial marking, providing a lightweight, cordless, and fully portable solution for engraving on a wide range of materials. This innovative device is particularly well-suited for applications involving large, heavy, or otherwise difficult-to-move workpieces, eliminating the constraints of traditional stationary marking systems.
It features a high-capacity 24V rechargeable lithium battery, enabling 6-8 hours of continuous operation. This cordless design enhances portability, eliminating power cable limitations and preventing unexpected shutdowns, making it ideal for on-site and remote industrial applications.
Portable & Ergonomic Design
Smart Power-Saving Mode
High-Performance Fiber Laser
Fast & Reliable Processing
Long-Lasting Battery & Continuous Operation
Convenient Storage & Transport
| Model | HT-FH20 | HT-FH30 | HT-FH50 |
| Laser power | 20w | 30w | 50W |
| Marking range | 75x75mm | ||
| Marking method | High-Precision two dimensional scanning system | ||
| Laser Wavelength | 1064mm | ||
| Output Frequency of Laser | 27-60Hz | ||
| Marking Speed | ≤10000mm/s | ||
| Operation System | Linux | ||
| Marking Line Type | dot,vector | ||
| Minimum line width | 0.1mm | ||
| Minimum character | 0.15mm | ||
| Repeating precision | 0.005mm | ||
| Cooling system | Air cooling | ||
| Positioning method | Red light positioning | ||
| Number of line of characters that can be marking | Any number of lines within the effective marking range | ||
| Marking Speed | 800 characters(depands on material and marking content) | ||
| Fonts | Standard Fonts of simplified Chinese English Numbers Traditional Chinese etc | ||
| File format | BMP、DXF、HPGL、JPEG、PLT | ||
| Bar code | CODE39、C0DE128、C0DE126、QR | ||
| Power supply | 500W / 100-240V / 50/60Hz | ||
| Temperature of Operation | 0-40° | ||
| Laser cabint dimensions | 255x135x200mm | 275x150x200mm | |
| Machine net weight | 6kg(laser head 1.25kg) | 6.5kg(laser head 1.25kg) | |
