Designed to be compact and durable with a fiber laser source for high-speed, energy-efficient engraving with superior beam quality for exceptional performance. The machine’s compact and portable design ensures easy transportation and setup, while the fully aluminum work platform provides unmatched stability and durability making.
| Model | HT-F20 | HT-F30 | HT-F50 |
| Power | 20W/30W/50W | ||
| Laser Wavelength | 1064nm | ||
| Fiber Laser Source | IPG/JPT/RAYCUS/MAX | ||
| Marking Area | 100x100mm-300x300mm Optional | ||
| Marking Depth | ≤2mm | ||
| Marking Speed | 7000mm/s | ||
| Minimum Line Width | 0.01mm | ||
| Minimum Character | 0.15mm | ||
| Repeated Precision | ±0.002mm | ||
| Controller (software) | JZC Controller & EzCAD2/EzCAD3 Hi W | ||
| Output Power of Laser | 10%~100% | ||
| Output Frequency of Laser | 1~600KHz | ||
| Operation Environment | Windows XP/7/8/10/11 | ||
| Cooling Mode | Aircooling | ||
| Power supply | 110V-220V/50Hz-60Hz | ||
| Total Power | 500W | 800W | 1000W |
acrylic, plastic, brick, glass, marble, tile, aluminum, copper, silver, gold, brass, titanium, and steel.
